5.
Refer to the following table to confirm the number on the Platen (a) that corresponds to the size of paper for print-
ing.
Number
2 254 mm (10 in) or 257 mm
3 355 mm (14 in)
4 406 mm (16 in), 420 mm, or 432 mm (17 in)
5 515 mm (20 in)
6 610 mm (24 in)
6.
Using the back of the Cleaning Brush, move the Switch to the side opposite ●, corresponding to the size of the paper
for printing.
In this case, note that you will move the switch in the opposite direction from the direction in step 4.
7.
Close the Top Cover.
iPF6300S
Dimensions
Troubleshooting > Problems with the printing quality
Paper Size
10"x12", 8"x10", or JIS B4
14"x17"
16-in. Roll (406.4mm), ISO A2, 17-in. Roll (431.8mm), or
ANSI C
JIS B2 or JIS B3
ISO A1, ISO A2, or 20"x24"
Setting the Blue Switch on the Platen
>
