iPF8400
2
Press ▲ or ▼ to select Yes, and then press the OK button.
The mode now switches from take-up mode to regular mode.
•
The printer will also switch from take-up mode to regular mode if you lift the Release Lever and cut the roll with
scissors instead of pressing the Cut button.
Note
3
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect the Settings/Adj. tab (
•
If the Tab Selection screen is not displayed, press the Menu button.
Note
4
Press the OK button.
The Set./Adj. Menu is displayed.
5
Press ▲ or ▼ to select Take-up Reel, and then press the OK button.
6
Press ▲ or ▼ to select Use Take-up Reel, and then press the OK button.
7
Press ▲ or ▼ to select Disable, and then press the OK button.

Loading the Rewind Spool on the Media Take-up Unit

Loading the Rewind Spool on the Media Take-up Unit

1
When using the Output Stacker, stow the Output Stacker before this procedure. (See "Storing the Output
Stacker.")
→ P.575
• Position the Basket Cloth and Basket Rod so they do not inter-
fere with the Media Take-up Sensor (wave portion). This may
Important
impair operation.
User's Guide
).
Loading the Rewind Spool on the Media Take-up Unit
579
