Canon imagePROGRAF iPF8400 User Manual page 487

iPF8400
Setting
5mm
20mm
• Cut Speed
This selects the auto cut speed.
Setting
Printer Default
Fast
Standard
Slow
• Calibration Value
When calibration has been carried out on the printer, use this setting to choose whether or not to use the results.
Setting
Printer Default
Use Value
Disregard Value
• Mirror
Specify whether to print a mirror image, as needed. Select this option to print a version of the document or image
with the left and right sides inverted.
• Unidirectional Printing
Select this checkbox to prevent problems such as misaligned lines and improve the print quality. However, the
printing speed becomes slower.
• High-Precision Text and Fine Lines
Print increasing ink impact accuracy, particularly for sharper text and fine lines. However, this takes more time
than regular printing.
•
When Highest (Max. No. of Passes) is selected as the print mode, High-Precision Text and Fine Lines cannot be
selected.
Note
User's Guide
*Select for Media Type that has no problem when printing with a standard size margin.
Select this when rubbing against the printhead occurs such as when using paper that tends to
curl.
The settings of the printer operating panel are applied.
Select this setting if cutting with the Standard setting is not clean.
Select this setting when you are not experiencing problems.
This helps prevent adhesive from sticking to the cutter and keeps the cutter sharp if you select it
when using adhesive paper.
The settings of the printer operating panel are applied.
The calibration results are used for printing.
The calibration results are not used for printing. Select this option to avoid changes to image color
tones during printing due to color calibration.
Paper Detailed Settings Dialog Box
Details
Details
Details
487
