Enter the width of the media size.
Height
Enter the height of the media size.
•
You can change the numbers by clicking either ▲ button or ▼ button.
Note
• Add button
Click the button to register the contents of the settings.

Curves Dialog Box

Curves Dialog Box

This dialog box appears when you click the Curves button on the Color Settings Sheet. You can set Channel and
other settings.
• Channel
Select from among RGB, Red, Green, or Blue.
•
Gray is displayed for monochrome printing and this selection cannot be changed.
Note
• Input
Enter an input value.
•
The allowed entry range is 0 to 255.
•
You can change the numbers by clicking either ▲ button or ▼ button.
Note
• Output
Enter an output value.
•
The allowed entry range is 0 to 255.
•
You can change the numbers by clicking either ▲ button or ▼ button.
Note
User's Guide
Curves Dialog Box
283
