Parts of the Output Stacker
Parts of the Output Stacker
a Output Stacker
A cloth tray that catches ejected documents.
b White tag
A point of reference for attaching the Output Stacker in the right direction.
570
c Basket Arm R and Basket Arm L
Holds the Basket Rod (tag side) attached to the Output Stacker. When the Output Stacker is not used, push it
down and store it next to the Stand Leg.
