Setting the Blue Switch on the Platen
5
Refer to the following table to confirm the number on
the Platen (a) that corresponds to the size of paper for
printing.
2
3
4
5
6
7
8
9
10
11
976
Number Dimensions
254.0 mm (10.00 in)
355.6 mm (14.00 in)
431.8 mm (17.00 in)
515.0 mm (JIS B2 or B3)
594.0 mm (ISO A1 or A2) or 609.6 mm (24.00 in)
841.0 mm (ISO A0 or A1)
914.4 mm (36.00 in)
1030.0 mm (JIS B0 or B1)
1066.8 mm (42.00 in)
1117.6 mm (44.00 in)
