User Manual of DS-7604 Series DVR
ALARM OUT
9 POWER
10 12V
11 GND

Product Application Diagram

Operating Your DVR

There are numerous ways to navigate and operate your DVR. You may use the Front Panel Controls, the
included IR (Infrared) Remote, a Mouse and the Soft Keyboard.

Using the Front Panel Controls

Your DVR comes with built-in front panel controls, as shown in the following figure:
The controls on the front panel include:
Status Indicators:
• POWER: the POWER indicator turns green when DVR is powered up.
Connector for alarm output (1 alarm output)
Switch for turn on/off the device
12VDC power supply
Ground(needs to be connected when DVR startup)
Figure 3. Product Application Diagram
Figure 4. DVR Front Panel Controls
11
