DS-9600/8600/7600NI-ST Series NVR
Quick Operation Guide
Version 2.1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-7608NI-ST and is the answer not in the manual?

Questions and answers

Summary of Contents for HIKVISION DS-7608NI-ST

  • Page 1 DS-9600/8600/7600NI-ST Series NVR Quick Operation Guide Version 2.1.2...
  • Page 2: Verify Contents

    Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer. This manual is applicable to DS-7608NI-ST, DS-7616NI-ST, DS-8608NI-ST, DS-8616NI-ST, DS-8632NI-ST; DS-9608NI-ST, DS-9616NI-ST, DS-9632NI-ST series NVR. Verify Contents Verify that the package contents are correct by checking the items against the packing list.
  • Page 3 Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR 3. Press the buttons on the panel of two sides and open the front panel. 4. Insert the hard disk along the slot until it is placed into position. 5. Repeat the above steps to install other hard disks onto the NVR. After having finished the installation of all hard disks, replace the front panel and lock it with the key again.
  • Page 4 Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Steps (for DS-8600NI-ST): 1. Remove the cover from the NVR by unfastening the screws on the back and side. 2. Install the HDD in the HDD rack using the provided screws. Fasten the screws on the button to fix the HDD.
  • Page 5 Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Steps (for DS-7600NI-ST): Remove the cover from the DVR by unfastening the screws on the rear and side panel. Connect one end of the data cable to the motherboard of DVR and the other end to the HDD. 3.
  • Page 6: Front Panel

    Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Front Panel DS-9600NI-ST DS-8600NI-ST Name Function Description ALARM Alarm indicator turns red when a sensor alarm is detected. Ready indicator is normally blue, indicating that the device is functioning READY properly. Status indicator turns blue when device is controlled by an IR remote. STATUS Indicator turns red when controlled by a keyboard and purple when IR remote and keyboard is used at the same time.
  • Page 7 Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Switch to the corresponding channel in Live view or PTZ Control mode. Input numbers and characters in Edit mode. Switch between different channels in All-day Playback mode. Alphanumeric Buttons The light of the button is blue when the corresponding channel is recording;...
  • Page 8 Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR In the PTZ Control mode, it is used to adjust the iris of the PTZ camera. The DIRECTION buttons are used to navigate between different fields and items in menus. In the Playback mode, the Up and Down button is used to speed up and slow down recorded video.
  • Page 9 Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Tx/Rx: TX/RX indicator flickers green when network connection is functioning normally. Switch between the numeric or letter input and functions of SHIFT the composite keys. (Input letter or numbers when the light is out;...
  • Page 10 Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR speed up and slow down record playing, and the Left and Right buttons are used to move the recording 30s forwards or backwards. In the image setting interface, the up and down button can adjust the level bar of the image parameters.
  • Page 11: Rear Panel

    Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Rear Panel DS-9600NI-ST: DS-9600NI-ST DS-8600NI-ST Item Description VIDEO OUT BNC connector for video output. CVBS AUDIO OUT RCA connector for audio output. This connector is synchronized with CVBS video output. VGA AUDIO OUT RCA connector for audio output.
  • Page 12: Peripheral Connections

    Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR GROUND Ground (needs to be connected when NVR starts up). AC 100V ~ 240V AC 100V ~ 240V power supply. POWER Switch for turning on/off the device. Item Description VIDEO OUT BNC connector for video output. AUDIO OUT BNC connector for audio output.
  • Page 13: Alarm Connection

    Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR To connect to an AC/DC load, use the following diagram: For DC load, JP4 can be used within the limit of 12V/1A safely. If the interface is connected to an AC load, JP4 should be left open.
  • Page 14 Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR To connect RS-485 devices to the NVR: Disconnect pluggable block from the RS-485 terminal block. Unfasten stop screws from the pluggable block, insert signal cables into slots and fasten stop screws. Ensure signal cables are in tight. Connect pluggable block back into terminal block.
  • Page 15: Specifications

    Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Specifications Table 1 Specifications of DS-9600NI-ST Model DS-9608NI-ST DS-9616NI-ST DS-9632NI-ST IP video 8-ch 16-ch 32-ch input Video/Audio input 1-ch, BNC (2.0 Vp-p, 1kΩ) Two-way audio Recording 5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF resolution /QCIF 1-ch, BNC (1.0 Vp-p, 75 Ω)
  • Page 16 Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Table 2 Specifications of DS-8600NI-ST Model DS-8608NI-ST DS-8616NI-ST DS-8632NI-ST IP video 8-ch 16-ch 32-ch input Video/Audio input 1-ch, BNC (2.0 Vp-p, 1kΩ) Two-way audio Recording 5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF resolution /QCIF 1-ch, BNC (1.0 Vp-p, 75 Ω)
  • Page 17 Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Table 3 Specifications of DS-7600NI-ST Model DS-7608NI-ST DS-7616NI-ST IP video input 8-ch 16-ch Video/Audio input 1-ch, BNC (2.0 Vp-p, 1kΩ) (Two-way audio) Audio in Recording 5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF...
  • Page 18: Hdd Storage Calculation Chart

    Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used 128K 160K 192K 224K...
  • Page 19: Menu Operation

    Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Menu Operation Menu Structure The menu structure of the DS-9600/8600NI-ST Series NVR is shown as below: Startup and Shutdown Proper startup and shutdown procedures are crucial to expanding the life of the NVR. To start your NVR: 1.
  • Page 20: Using The Start Wizard

    Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Using the Start Wizard By default, the Start Wizard will start once the NVR has loaded. Operate the Start Wizard by following the steps described below: Steps: The Setup Wizard will walk you through some important settings of your NVR. If you don’t want to use the Setup Wizard at this time, click the Cancel button.
  • Page 21 Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Note: Dual NIC is supported by DS-9600NI-ST only. Click Next button after you configure the network parameters to enter the HDD Management window. To initialize the HDD, click the Init button. Initialization will remove all the data saved in the HDD. Click Next button.
  • Page 22: Live View

    Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Click OK to complete the startup Setup Wizard. Live View Some icons are provided on screen in Live View mode to indicate different camera status. These icons include: Live View Icons In the live view mode, there are icons at the right top of the screen for each channel, showing the status of the record and alarm in the channel, so that you can find problems as soon as possible.
  • Page 23: Configuring Basic Parameters Of Ip Cameras

    Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Check the checkbox of certain cameras to be added. Click Quick Add to add the camera. To add other IP cameras: On the left side of the interface, you can enter the IP address, protocol, management port, and other information of the IP camera to be added.
  • Page 24: Ptz Control

    Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Click Apply to save the settings and click OK to exit the interface. Explanation of the icons: Edit basic parameters of the camera Delete the IP camera Get the live view of the camera PTZ Control Follow the procedure to set the parameters for PTZ.
  • Page 25: Instant Playback By Channel

    Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Description of the PTZ toolbar icons Icon Description Icon Description Icon Description Direction button and Zoom+, Focus+, Zoom-, Focus-, Iris- the auto-cycle button Iris+ The speed of the Light on/off Wiper on/off PTZ movement Zoom Middle Preset...
  • Page 26 Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Front Panel: press PLAY button to play back record files of the channel under single-screen live view. Under multi-screen live view, record files of the top left channel (not masked) will be played back. Note: pressing numerical buttons will switch playback to related channels during playback process.
  • Page 27 Quick Operation Guide of DS-9600/8600/7600NI-ST Series NVR Enter Export interface, choose backup device and press Export button to start exporting. Check backup result. Choose the record file in Export interface and press button to check it.
