Quick Start Guide
NOTE: For more detailed information, refer to the Users Manual on
the CD-ROM. You must use your PC or MAC to access the files.
First Choice For Security Professionals
DS-9000 Series Hybrid DVR
DS-7600 Series Hybrid DVR
DS-9600 Series NVR
DS-9100 Series
DS-8100 Series
DS-7300 Series
DS-7200 Series
Hybrid DVR
NVR
Analog DVR
www.hikvisionusa.com
Advertisement
Table of Contents
Related Manuals for HIKVISION DS-9000 Series
Summary of Contents for HIKVISION DS-9000 Series
-
Page 1: Quick Start Guide
First Choice For Security Professionals Quick Start Guide Hybrid DVR DS-9000 Series Hybrid DVR DS-7600 Series Hybrid DVR DS-9600 Series NVR Analog DVR DS-9100 Series DS-8100 Series DS-7300 Series DS-7200 Series NOTE: For more detailed information, refer to the Users Manual on the CD-ROM. -
Page 2: Quick Start
7. Playback 8. Backup 9. Configure IP Cameras (Only for DS-9000 Series Hybrid DVR, DS-7600 Series Hybrid DVR and DS-9600 Series NVR) NOTE: For more detailed information, refer to the Users Manual on the CD-ROM. You must use your PC or MAC to access the files. -
Page 3: Front Panel Description
HDD Cables Rack Mount Ears Quick Start Guide Manual/Software CD Front Panel Description: **Please note DS-9000 Series Hybrid DVR shown above** **Please note DS-9100 Series Analog DVR shown above** 1. Power Button 5. Alphanumeric Buttons 2. IR Receiver 6. Control Buttons 3. -
Page 4: Startup And Shutdown
IP Dome IP Camera Note: DS-9000 Series Hybrid DVR and DS-7600 Series Hybrid DVR support both Analog and IP cameras. DS-9600 Series NVR supports only IP cameras NOTE: The DVR’s Menu is only shown on VGA monitor 3. Startup and Shutdown To startup your DVR: 1. -
Page 5: Formatting A Disk
First Choice For Security Professionals 3. Startup and Shutdown (cont.) To shutdown your DVR: OPTION 1: Standard Shutdown 1. Enter the Shutdown menu by going to Main Menu > Maintenance > Shutdown. 2. Select the Shutdown button. 3. Click the Yes button. OPTION 2: Manual Shutdown 1. -
Page 6: Setting Date And Time
4. Formatting a Disk (cont.) 3. Click the Add button. 4. A confirmation message will appear on the screen. Click the Yes button to continue formatting process. 5. A format progress bar will be shown on the menu. After the disk has been formatted, the status of the disk will change to Active. - Page 7 First Choice For Security Professionals 6. Recording To setup quick recording schedule: 1. Enter the Quick Schedule Configuration menu by going to Main Menu > Recording Configuration > Quick Schedule Configuration. 2. Select the camera to configure from the camera drop down menu.
- Page 8 First Choice For Security Professionals 7. Playback Playback from Search: 1. Enter the Playback menu by going to Main Menu > Playback. 2. Set the search parameters by selecting cameras to search and date to search on. 3. The search results will be shown on the timeline with blue bars designating recorded files.
- Page 9 8. Backup Backup recorded files (Export): 1. Enter the File Management menu by going to Main Menu > System Configuration > File Management 2. Select desired parameters to search for files to backup. 3. Select the files to backup. You may also click the Play button to verify that these files are indeed the ones you would like to backup.
-
Page 10: Network Connection
Network Connection Using Internet Explorer All Hikvision products use the default IP address of 192.0.0.64 1. Connect a CAT5 or CAT6 cable from the DVR to a PC or Laptop computer. Note your laptop or PC computers existing address, such as: 192.0.0.62... -
Page 11: Add Ip Cameras
10. Add IP Cameras Adding IP Cameras Directly on the Hybrid DVR and NVR’s Menu: 1. Enter the Add/Remove Cameras menu by going to Main Menu > Cameras Setup > Add/Remove Cameras. 2. Select the IPC tab. 3. Click the Discover button to automatically detect connected IP cameras on the network. 4. - Page 12 First Choice For Security Professionals 908 Canada Court City of Industry, CA 91748 U.S.A. www.hikvisionusa.com 1104v1...
