Front

Printer parts

Printer parts
Front ................................................................................................................................................................... 684
Back ................................................................................................................................................................... 686
Top Cover (Inside) ............................................................................................................................................. 687
Carriage ............................................................................................................................................................. 688
Ink Tank Cover (Inside) ...................................................................................................................................... 689
Stand .................................................................................................................................................................. 690
Media Take-up Unit ............................................................................................................................................ 691
Control Panel ...................................................................................................................................................... 648

Front

Front
a Top Cover
Open this cover to install the Printhead, load paper, and remove any jammed paper from inside the printer as nee-
ded. (See "Top Cover (Inside).")
b Cutter Groove
Paper is cut (using the cutter or manually with scissors) over this groove.
c Ejection Guide
Guides printed documents as they are ejected. Raise the guide when loading a roll.
684 d Roll Holder Slot
Slide the Roll Holder into this slot.
→P.687
