Page Options Dialog Box (Windows)
Crop Marks

Page Options Dialog Box

Page Options Dialog Box

This dialog box appears when you select Page Options from the File menu. This allows you to configure the roll paper
length, object layout order, and margins of Free Layout.
• Roll Paper Length
Set the length of one page to print on roll paper.
The following settings are available for roll paper length.
Auto Settings
Manual Settings
•
Available only if rolls are selected in Paper Source.
•
You can input between 203.2 and 18000.0(mm) (between 8.00 and 708.66(inch)).
Note
•
You can change the numbers by clicking either ▲ button or ▼ button.
• Order
Set the object layout order.
The following settings are available for order.
Upper Left to Right
Upper Left to Bottom
Upper Right to Left
Lower Left to Top
222
Setting
You can print with the crop marks.
Setting
The one-page length to be printed on roll paper is automatically set so that the laid-out objects
are printed on one page.
You can input the length of one page to print on roll paper in numerical characters.
Setting
The objects are laid out from upper left to right.
The objects are laid out from upper left to bottom.
The objects are laid out from upper right to left.
The objects are laid out from lower left to top.
Details
Details
Details
