Adjustment When Installing the Printhead

13
Press the Back button.
14
Press ▲ or ▼ to select Register Setting, and then press the OK button.
15
Press ▲ or ▼ to select Yes, and then press the OK button.
The adjustment value is now registered, and adjustment is complete.
Adjustment When Installing the Printhead Adjustment When Installing the Printhead
Printhead position adjustment is executed when the printhead is first installed.
This adjustment should be executed in the following situations.
If adjusting the printhead position has not been performed such as due to an error during initial setup
•
If Rep.P.head Print in the Control Panel menu is set to Off and adjusting the printhead position has not been per-
•
formed when replacing the printhead
•
We recommend that the same paper as the paper included with the printer is used for this adjustment.
Note
Items to Prepare
When Using Rolls
When Using Sheets
Perform adjustment as follows.
1
Load paper.
• Attaching the Roll Holder to Rolls
•
Loading Rolls in the Printer
• Loading Sheets in the Printer
Important
2
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect the Settings/Adj. tab (
•
Note
3
Press the OK button.
The Set./Adj. Menu is displayed.
4
Press ▲ or ▼ to select Adjust Printer, and then press the OK button.
5
802
Press ▲ or ▼ to select Head Posi. Adj., and then press the OK button.
6
Press ▲ or ▼ to select Other, and then press the OK button.
An unused roll at least 254.0 mm (10.00 in) wide
Seven sheets of unused paper, A4/Letter size (or one sheet when using A2)
→P.533
→P.555
•
Always make sure the loaded paper matches the type of paper specified on the printer. Adjustment cannot be com-
pleted correctly unless the loaded paper matches the settings.
).
If the Tab Selection screen is not displayed, press the Menu button.
→P.530
