iPF9400
The Media Take-up Sensor cord is not connected to the Right Media Take-up Unit
correctly.

The size of clear film cannot be detected

The size of clear film cannot be detected
Cause
The Platen is soiled with ink or other substances.

Margins are wide

Margins are wide
Rolls are advanced a specific amount before cutting to prevent problems with cutting and paper ejection.

When printing on thin roll paper, the printed surface becomes scratched

When printing on thin roll paper, the printed surface becomes scratched
Cause
The roll paper has sagged during printing, scratching
the surface of the paper and causing wrinkle creases
in the paper.
User's Guide
Cause
Corrective Action
Open the Top Cover and clean the entire Platen.
(See "Cleaning Inside the Top Cover.")
Cause
Set Roll Tension to High in the Control Panel menu.
(See "Menu Settings.")
If you change the Roll Tension setting, We recommend that you perform Adj. Quali-
ty.
(See "Automatic Banding Adjustment.")
The size of clear film cannot be detected
Corrective Action
Remove the foreign object from the Media Take-up Sensor
path. Arrange the Basket Cloth and Basket Rod so they do
not interfere with the Media Take-up Sensor.
Reconnect the Media Take-up Sensor cord as follows.
1.
Turn the printer off.
2.
Disconnect the Media Take-up Sensor cord from the
Right Media Take-up Unit and reconnect it firmly, all the
way in.
3.
Turn the printer on.
(See "Using the Media Take-up Unit.")
If the Media Take-up Unit continues rotating, contact your
Canon dealer for assistance.
→P.861
Corrective Action
This operation is normal.
Corrective Action
→P.667
→P.806
→P.570
885
