In case the modifier is an asterix (*), the value
depends on the options of the symbology or on
the configured Code options. For details refer to
their own respective modifier tables. See
figures 4.06 up to 4.17.
Code length:
The code length is transmitted as 2 digits,
representing the decimal number of data
characters transmitted, excluding prefix and
suffix characters. For 2D bar codes the code
length is transmitted as 6 digits. It is also
possible to send for both 1D and 2D codes the
length as 6 digits.
These direct input characters count as 1 entry
of the 4 permissible entries for a prefix or suffix.
Example:
If you want to configure the prefix
<code identifier>:<code length>:
scan the following labels:
<SET>
<Set prefix all>
<Code identification>
<:>
<Code length>
<:>
<END>
If you want to use the code identifiers, but need
another code identifier for Code 39, you scan
the following labels:
<SET>
<Set prefix all>
<Code identification>
<:>
<Set prefix Code 39>
<$>
<:>
<END>
OPTICON Universal menu book
U86
Fig. 4.04. Set prefix and suffix
OPTICON Code identifiers
UPC-A
UPC-A +2
UPC-A +5
UPC-E
UPC-E +2
UPC-E +5
EAN-13
EAN-13 +2
EAN-13 +5
EAN-8
EAN-8 +2
EAN-8 +5
Code 39
Code 39 Full ASCII
Italian Pharmaceutical
Codabar
Codabar ABC
Codabar CX
Industrial 2of5
Interleaved 2of5
S-Code
Matrix 2of5
Chinese Post
IATA
MSI/Plessey
Telepen
UK/Plessey
Code 128
GS1-128
Code 93
Code 11
Korean Postal Authority code
Intelligent Mail Barcode
POSTNET
GS1 Databar
CC-A
CC-B
CC-C
Codablock F
DataMatrix
Aztec
Aztec Runes
Chinese Sensible code
QR code
Micro QR Code
Maxi Code
PDF417
MicroPDF417
- C
- F
- G
- D
- H
- I
- B
- L
- M
- A
- J
- K
- V
- W
- Y
- R
- S
- f
- O
- N
- g
- Q
- w
- P
- Z
- d
- a
- T
- T
- U
- b
- c
- 0
(zero)
- 3
- y
- m
- n
- l
- E
- t
- o
- o
- e
- u
- j
- v
- r
- s
