Opticon OPL-9815 Quick Start Manual

gETTing sTarTED

read this Quick start guide carefully before installing
and/or using this product.

Confirm whaT's in ThE box

DATA COLLECTOR
a portable terminal with a barcode scanning feature.
QUICK START GUIDE
Provides product information and instructions.
HAnD STRAP
* The number of accessories may differ depending on
the product configuration. if any of the accessories
are damaged or missing, please contact your local
representative.

insErT or rEmovE a baTTEry

STEP 1
open the battery cover before inserting or
removing a battery.
STEP 2
make sure that the battery contacts are properly aligned
with the contacts of the terminal.
STEP 3
Close the battery cover.

ChargE ThE TErminaL

To insure proper operation after inserting the battery, it
is advised to fully charge the data collector in the cradle
for up to 5 hours.
QUICK START GUIDE
OPL-9815
Trigger key
Display
LED
Laser barcode scan engine
