2.3.1. Bluetooth address

To enable the Bluetooth reader to communicate
to another Bluetooth device, the Bluetooth
address of that device must be configured in
the reader.
The Bluetooth address can be found on the
other device. Mostly it is displayed on the
product label as a 12 digits number or a
number with 6 hex digit pairs.
To configure an Opticon Bluetooth bar code
reader to connect to a third party Bluetooth
dongle, the following steps must be taken:
• step 1 - retrieve the dongle's MAC address
• step 2 - set the reader to connect directly to a
computer
• step 3 - set the MAC address of the dongle in
the reader
• step 4 - establish connection to the Bluetooth
module
OPTICON Universal menu book
Example for manually connection and
configuration:
Example Step 1.
The following information is retrieved from the
dongle's Bluetooth manager:
Dongle make/type: MSI MS6967
Bluetooth Address: 00 04 12 34 AF 56
Secure Connection: Not Required.
Example Step 2.
• read the following codes:
<SET>
<Connect to PC>
Example Step 3.
Note: when reading the same menu label
again, it is necessary to keep the reader away
from the menu book for about one second.
• from this chapter read:
<Set bluetooth address label>
• from the chapter Direct input numeric read:
<0>
keep reader away from menu book...
<0>
keep reader away from menu book...
<0>
<4> <1> <2> <3> <4>
• from the chapter Direct input character read:
<A> <F>
• from the chapter Direct input numeric read:
<5> <6>
• from this chapter read:
<End bluetooth address label>
<END>
Example Step 4.
• read the command label:
<Manually connect>
Commands for (dis)connection:
In case a Bluetooth address is already
configured, the reader can be manually
connected or disconnected with the
following command labels:
• connection: <Manually connect>
• disconnection: <Manually disconnect>
