A. TROUBLE SHOOTING
The trouble shooting diagram can be of help if
your reader does not operate as expected. If
any problem is not covered or solved with this
diagram you need to contact your dealer.
Whether the reader operates or not can be
checked in the following way:
• it should beep after the power has been
switched ON
• it should either react on a trigger(if any) or it
should emit light at the scan side of the
reader (LEDs)
See figure A.01.

Fig. A.01. Trouble shooting

Reader No Check
operates? cabling
Yes
No
Problems Reads
reading menu? bar codes?
Yes
Garbage
on screen?
reader interface
Scans Reads any
No
SET/END? label?
Yes
Software and menu do not match.
Use matching menubook
Low buzzer indicates
unsupported option
OPTICON Universal menu book
No Setup reader or
contact dealer
Yes
No Setup bar code
options
Yes
Setup
Reader defect
No
contact dealer
Yes
U131
