3.3.18. Options for Composite Codes

CC-A is a modified MicroPDF417 version.
CC-B is standard MicroPDF417.
CC-C is standard PDF417.
Maximum data capacity:
• CC-A: 56 characters
• CC-B: 338 characters
• CC-C: 2361 characters
Symbol size:
• 1D part: see RSS and EAN codes
• Composite part: CC-A and CC-B same as
MicroPDF417, CC-C same as PDF417
Error correction:
• 1D part: only error detection
• Composite part: Reed Solomon error
correction
Encodable characters:
• ASCII values 0 - 127 ( ISO 646 )
• ASCII values 128 - 255 ( ISO 8859-1, Latin
alphabet No. 1, extended ASCII )
• with ECI: many other character sets
For string format of composite codes see figure
3.41 or 3.42 or 3.43.
Options for Composite codes:
• enable composite code
• ignore link flag
• output mode
For string format of composite codes see figure
3.44.
OPTICON Universal menu book
Fig. 3.41. Options for Composite Codes
(1 upto 73 characters)
Fig. 3.42. Options for Composite Codes
(1 upto 73 characters)
Fig. 3.43. Options for Composite Codes
(1 upto 73 characters)
Composite Composite
Enable Enable
BHE BHE
BHE BHE
BHE BHE
BHE BHE
BHE BHE
BHE BHE
BHF BHF
BHF BHF
BHF BHF
BHF BHF
BHF BHF
BHF BHF
U74
Composite A
1D data composite data
(1 upto 56 characters)
Composite B
1D data composite data
(1 upto 338 characters)
Composite C
1D data composite data
(1 upto 2361 characters)
Fig. 3.44. Combined options Fig. 3.44. Combined options
for Composite Codes for Composite Codes
Output Output
Link Link
Mode Mode
Flag Flag
RP RP BL0 BL0 1D / 1D+2D
RP RP BL1 BL1 2D / 1D+2D
RP RP BL2 BL2 1D / 2D / 1D+2D
RQ RQ BL0 BL0 1D+2D
RQ RQ BL1 BL1 1D+2D
RQ RQ BL2 BL2 1D+2D
RP RP BL0 BL0 1D
RP RP BL1 BL1 2D
RP RP BL2 BL2 1D / 2D
RQ RQ BL0 BL0 1D
RQ RQ BL1 BL1 2D
RQ RQ BL2 BL2 1D / 2D
Output Output
Result Result
1D / 1D+2D
2D / 1D+2D
1D / 2D / 1D+2D
1D+2D
1D+2D
1D+2D
1D
2D
1D / 2D
1D
2D
1D / 2D
