DTT VoIP2All  USER MANUAL
Chapter 1: Installing SIM Cards & Connecting Cables
Chapter 1.1: Hardeware Overview
The gateway consists from four main parts:

Chapter 1.2: Installing the SIM Cards in the Cellular Cards

Insert the SIM cards into the VoIP
Note: To extract the SIMs you need to push and release the SIM, the SIM will be released from the switch, and then pull it
out.
Chapter 1.3: Connecting the Cables
There are two sets of LAN and COM connectors on the master card marked ST1 and ST2. The
2
VoIP
ALL  currently  use  only  the  ST1  connectors  in  the  left.  (ST2  connectors  in  the  right  are
currently not in use.)




VoIP
2
All™ Series: 4 Channel Gateway User Manual
The  Master  –  Contains  a  AudioCodes™  DSP  processor  with  a  Linux  based  operating
system.  Using  a  Linux  operating  system  run  the  'v2g'  program  that  operates  the
gateway.
The Slave – Contains 4 cellular ports. Each port has one local SIM.  Each card has one
antenna connection for all 4 ports. The card is controled by two programble processors.
Each cellular port has 1 local SIM.
On the bottom of the each cellular port, there are  labeled slots for the local SIMs.
Position the SIM in the slots so the SIM metal contacts face upward and the snubbed
triangle  inwards into the device.
Gently insert the SIM until you hear a click.
The SIM is now in place.
LAN  cable  ‐  The  LAN  cable  is  used  to  connect  the  system  to  the  internet  network.
Connect the LAN line to the left RJ‐45 marked LAN (the right RJ‐45 marked LAN is not
in use).

Antenna – Connect one antenna for all the four channels. Position the antennas  at least
20 centimeters apart and more then 1.5 meters from the VoIP
Power Supply ‐ Connect the power supply from your 110‐240V 50‐60Hz power outlet to
2
the VoIP
ALL Gateway power connector.
Com  Cable  –  Connect  the  Com  Cable  from  the  PC  RS‐232  comport  to  the  left  RJ‐45
marked  COM  (the  right  RJ‐45  marked  COM  is  not  in  use).  The  com  connection  is  not
essential for day to day use.
2
ALL as follows:


2
ALL.
