DTT USER MANUAL
After pressing the 'Synchronization' button, the getaway will read the SIMs list from each SIM
Server it is connected to. All the SIMs in the SIM Servers will appear at the list. The list is
arranged according to SIM servers. Each SIM Server has cards called 'cards' (starting from card
1). Each card has the SIMs from 1 to 32 according to their location on the card.
For every SIMs setting may be defined individually.
•
•
•
•
•
•
•
•
•
•
This setting will take effect when the SIM will register in the GSM network.
VoIP 2 All™ Series: 4 Channel Gateway User Manual
PIN Code – The PIN Code for the SIM when the SIM is PIN Code protected.
CLIR – Show or Hide the number of the SIM.
Net ID – Locking the SIM on a specific network.
BCCH – Locking the SIM on a specific BCCH. When empty it will lock on the best
reception BCCH.
BCCH rssi – The minimum reception for rotation.
BCCH Timer – This function rotates the BCCH. The rotation is preformed according to
the BCCH Timer, measured in seconds, between all BCCH, which have better reception
than the BCCH rssi.
Bill Interval – The interval for each unit (see Chapter 4.2.1).
Units per Interval – The units for each interval (see Chapter 4.2.1).
Current Balance – The total amount of units for the SIM (See Chapter 4.2.1).
Recharge Value – Currently not in use.
32
