DTT USER MANUAL
3. Press the 'Update' button of the user.
4. Press 'OK' to confirm update.
Deleting a User from the List
To delete a user:
1. Press the 'Delete' button of the user (located at the end of the user line in the list).
2. Press 'OK' to confirm the delete.
Searching for a User
To find a user in the list:
1. In the 'Search Field' box enter the field to search by.
2. Enter the Value to search.
3. Press the 'Search' button.
4. The list will show all the users that come up on the search.
5. To return to the complete list press the 'All Users' button.
Chapter 8.2: User Capabilities
DISA
The DISA is a way for a GSM mobile phone to call back to the VoIP extension that called it.
Settings:
1. Change the 'Capabilities' value to 1 to enable the DISA for the user.
2. When a call from the VoIP to the GSM number of the user is made, the Gateway will save
the number of the extension that called it.
3. Enter in the DISA box (in the 'Prefixes' tab located in the 'VoIP' window), the number of
seconds the Gateway will remember the extension number.
4. In the defined time, the user wishes to call the Gateway from the GSM number, the
Gateway will give him a dial tone to call. The user may dial any number or press * to return
to the extension that called last.
5. If a few extensions called the user, Pressing * will go to the first extension that called, upon
the next GSM call, dialing * will go to the next extension that called.
6. Each extension number can be called once.
Callback
The Callback feature is a way for the user to make the Gateway call the user back and bill the call
at the expense of the SIM.
1. Change the 'Capabilities' value to 8 to enable the Callback for the user.
2. When a call comes from the GSM number of the user, the Gateway will disconnect the call
and call him back.
3. The user will get a dial tone to make a call.
Note: The Gateway will make a callback to the user's GSM number. Verify that the prefix of this number is on the prefixes
table and the Remove Prefix box beside if it isn't checked.
VoIP 2 All™ Series: 4 Channel Gateway User Manual
34
