DTT USER MANUAL
The connection between the Gateway and the SIM Server is limited to the time that the
Gateway is registered with a SIM from the SIM Server.
When the SIM server is operating behind a firewall, ports 2008 and 2009 should be open for the
operation of the SIM server.
Port 2007 should be open for remote access with the PC.
The Gateway may connect to an unlimited amount of SIMs in the SIM Server.
To view the SIM's that are in the SIM server 'Add' the SIM Server to the 'SIM Servers List'.
Viewing the SIM's in a SIM Server
1. Go to the 'SIM Servers List'.
2. Enter the IP address of the SIM Server.
3. Enter the port of the SIM Server; the default port for a VoIP
4. Press the 'Save List' button.
Press the 'Synchronization' button. The gateway will connect to all SIM Servers and will read all
the SIM lists.
In the 'SIM Server Setting' list you will see all the SIMs from the SIM Servers.
The list is arranged accordingly to SIM servers.
Each SIM Server has cards starting from card1 to card8. Each card has the SIMs from 1 to 32
according to their location on the card.
*Note: These tables are saved in the PC software files only; it is not saved on the Gateway. So if
you connect from another PC it will not automatically appear.
Chapter 3.11: Assigning a SIM to Work in a Port at a Specific Time
On the 'Available SIMs' list, the local SIM (L1) and all the SIMs from the SIM Servers are visible.
Each SIM Server SIM listing contains its location on the SIM Server and its IMSI number.
To assign a SIM to work at a specific time:
1. Go to the 'Ports' window.
2. Select a port from the list of the ports on the left.
3. Open the 'Time Table' tab.
4. In the 'Type' category, select the form of the timetable: monthly or weekly.
5. In the 'Swapping Type' category, select 'time table.'
6. Select a SIM from the list of available SIMs at the top.
7. The top row of the Timetable represents dates and the left column represents hours.
8. Each time slot is for a period of one hour.
9. Left click will select the SIM for this time slot and mark it with it's corresponding number.
10. You can mark a range of time by dragging the mouse while holding the left click.
11. To un‐select time slots simply click on it again.
12. You are unable to choose a SIM that is already in use at that time in another port on the
Gateway.
13. After setting all the needed SIMs press 'Save'.
14. After setting the needed changes on all the ports press 'apply' to activate.
VoIP 2 All™ Series: 4 Channel Gateway User Manual
2
ALL SIM Server is 2009.
