DTT VoIP2All USER MANUAL
The VoIP
external SIM Server could be a SIM Server unit or another Gateway with a SIM Server program.
When the Gateway needs to register SIMs from the SIM Server, it will connect to the SIM Server
with port 2009 and will request the data of the SIM. All the information will be passed through
port 2008. The duration of the connection between the Gateway and the SIM Server is limited to
the time that the Gateway is registered with a SIM from the SIM Server. When the SIM server is
operating behind a firewall, ports 2008 and 2009 should be open for the operation of the SIM
server. Port 2007 should be open for remote access with the PC. The Gateway can connect to
SIMs of 16 of SIM Servers at the same time. The SIM Server can connect to 100 Gateways at the
same time.
Open the 'Virtual SIM' window:
Chapter 7.1: Connecting to SIM Server
To view the SIMs that are in the SIM server Add the SIM server to the 'SIM Servers List'.
Viewing the SIMs of the SIM Server
1. Go to the 'SIM Servers List'.
2. Enter the IP address of the SIM Server you want to view is SIMs.
3. Enter the port of the SIM Server; the default port for a VoIP
4. Press the 'Save List' button.
5. Press the 'Synchronization' button. The getaway will connect to each SIM Server on the List
and will read from him the SIMs list.
In the 'SIM Server Setting' list you will see all the SIMs from the SIM Servers.
The list is arranged according to SIM servers. Each SIM Server has cards starting from card1 to
card8. Each card has the SIMs from 1 to 32 according to their location on the card.
These tables are saved in the PC software files only; it is not saved on the Gateway. So if you
connect from another PC it will not automatically appear.
Chapter 7.2: The SIM Server settings
VoIP 2 All™ Series: 4 Channel Gateway User Manual
2
ALL Gateway can connect to SIMs in both the internal and external SIM Servers. An
2
ALL SIM Server is 2009.
31
