DTT USER MANUAL
Chapter 6.5: working with Local SIM
For each GSM port there is a local SIM. This SIM in on the GSM card and can work only with that
GSM port. There are two basic modes of working with the local SIM; active by default, or work
by timetable.
Local SIM active by default
In this mode the local SIM will register in the cellular network automatically when inserted in the
SIM socket.
1. Open the 'ports' window.
2. On the left side there is a list of all the ports, select 'General'
3. Set the 'Default SIM' parameter to 'Enable'.
4. Insert the SIMs to the GSM port's local SIM sockets.
5. Open the 'Monitor' to view the status of the cellular ports.
Local SIM works by timetable
In this mode the local SIM will register in the cellular network according to the timetable.
1. Open the 'ports' window.
2. At the left side you will see list of all the ports, select 'General'
3. Set the 'Default SIM' parameter to 'Disable'.
4. Select a GSM port from the list at the left.
5. Open the timetable for that port.
6. Select (L1) from the 'Available SIMs' list.
7. Select at the timetable the hour (at the left), and the day (at the top) the local SIM will
work at.
8. Mark that time slot at the timetable.
9. Insert the SIMs to the GSM ports local SIM sockets.
10. At the defined time, the local SIM will register in the cellular.
Chapter 7: SIM Server
VoIP 2 All™ Series: 4 Channel Gateway User Manual
•
Units per Interval – The units for each interval (see Chapter 4.2.1).
•
Recharge Value, Current Balance – Currently not in use.
30
