DTT USER MANUAL
Use this window to restrict the Gateway to work only with a specific range of SIP IP addresses.
There are two restrictions tables, Enable IPs and Deny IPs.
When the IP address is restricted, all the messages from that IP will be blocked. You will not be
able to call That SIP or to register the SIP.
The table is for a range of addresses.
If you need to block only one IP, setup the start and the end to the same IP.
If Enable IPs and Deny IP's are not set
All the IPs are enabled.
Only the Enable IPs is set
The IPs in the range will be allowed, all other IPs will be denied.
Only the Deny IPs is set
The IPs in the range will be denied, all other IPs will be allowed.
Enable IPs and deny IPs is set
The IPs in the range of the Enable IP's will be allowed, with the exception of: the range of IP's in
the Deny IP's.
Chapter 5: System Setting
Press:
Chapter 5.1: General Setting
Press the General tab to set the Clock and the Password.
Setting the Clock
1. Select in the 'Date' box the date of the VoIP
2. Enter in the 'Time' box the time of the VoIP
3. Select in the 'Date Format' ' display preference, (Day:Month:Year) or (Year:Month:Day).
4. Press Save to change the time and date.
Restarting the VoIP
To restart the Gateway, press the 'Restart System' button.
This will restart only the DSP with the Linux programs.
There is another way to restart the DSP ‐ press the 'Reset' button on the master card (near the
LAN connector).
VoIP 2 All™ Series: 4 Channel Gateway User Manual
to set system settings.
2
ALL Gateway
2
ALL Gateway.
2
ALL Gateway.
24
