DTT USER MANUAL
By default the Internal SIP Server works without authentication, you can register with no
password and you can choose any user name. The user name should be a number.
Registering a VoIP phone in the Internal SIP Server
1. Open the configuration page of the SIP phone.
2. Set up the following registration parameters:
•
•
•
3. Save settings.
4. Register with the new account.
5. Via the VoIP
registered.
Chapter 3.5: Working with a local SIM
For each cellular port there is one dedicated local SIM. This SIM can work only with that cellular
port. There are two basic modes of working with the local SIM, 'active by default' or 'work by
timetable.'
Setting the Local SIM to be active by default
In this mode the local SIM will register in the cellular network automatically when inserted in the
SIM socket.
1. Open the 'ports' window.
2. On the left you will see list of all the ports, select 'General.'
3. Set the 'Default SIM' parameter to 'Enable.'
4. Insert the SIM to the cellular port's local SIM socket.
5. Open the 'Monitor' to view the status of the cellular ports.
Fig: Cellular Port monitor
When the SIM is registered correctly ‐ the monitor window will change to a light green color
and the Net and SIM indicator will change from yellow to green.
Chapter 3.6: Assigning a Prefix to a Port
VoIP 2 All™ Series: 4 Channel Gateway User Manual
The "SIP Server IP Address" ‐ the IP address of the gateway.
The "SIP User ID" ‐ the chosen number for this extension (any number).
The 'Authentication Password' – may be left empty.
2
ALL PC management, open the 'SIP Status' window to see the SIP phone
12
