DTT VoIP2All USER MANUAL
•
•
•
•
•
4. Click on the next line in the table and then press "Save".
5. Press the 'Register Host' button, to register host in the external SIP Server.
6. After few seconds, Press "Refresh". If the registration succeeded, the Status will show
'Reg'. If registration failed, it will show 'Not Reg'.
7. Go to the 'Prefixes' window and define a prefix for this Host.
Working without registration
You can connect the VoIP
Servers are connected the gateway will be able to make calls to the SIP Server without
registering in it.
1. Get a SIP account from the external SIP.
2. Open the SIP tab in the VoIP window.
3. Add a new Host to the list with the SIP account information:
•
•
•
•
•
•
4. Click on the next line in the table and then press "Save".
5. Press "Refresh", the Status will show 'Reg'.
6. Go to the 'Prefixes' window and define a prefix for this Host.
Dialing to the IP PBX
To call from a GSM mobile phone through Gateway to extension in the IP PBX
Chapter 4.5: IP Restrictions
VoIP 2 All™ Series: 4 Channel Gateway User Manual
The 'IP Address' is the SIP Server IP address or name you want to register with.
The 'Port' is the number of the SIP Server port (the Default is 5060).
The 'User' is the user number or name.
The 'Secret' is the authentication password of the SIP account.
The 'Register' box, check it to register in the SIP.
2
ALL to an external SIP Server without registering. When the SIP
The 'Name' is the chosen name for this host connection.
The 'IP Address' is the SIP Server IP address or name you want to register with.
The 'Port' is the number of the SIP Server port (the Default is 5060).
The 'User' is the user number or name.
The 'Secret' is the SIP account password (when working with authentication).
The 'Register' box, leave empty so it will not register in the SIP.
Go to the 'Ports' window.
•
From the ports list, select this Host.
•
Setup the prefix of the host to the prefix of the PBX extensions (i.e. if all the PBX
•
extensions start with the digit 1, then the prefix of the host will be 1).
Setup the 'Remove Prefix' to 0.
•
Dial the number of the SIM card in port 1.
•
Hear a dial tone.
•
Dial the PBX extension number.
•
The Gateway will recognize the prefix of the Host (i.e. 1) and the call will be routed
•
to the IP PBX.
23
