DTT VoIP2All USER MANUAL
Using the basic setting, an incoming call from a port will receive a dial tone. The user may then
dial a number, the gateway will route the call according to the prefix of the dialed number.
To assign prefix to a port:
1. Open the 'Ports' window.
2. Select a port from the list on the left.
3. Press the 'Prefixes' tab to see the prefix table of the port.
4. Enter the Prefixes for this port.
When a dialed number starts with one of the prefixes in the list, the call will automatically
route to this port.
If the prefix of a port is '*', then all the calls that do not conform to the other port's will be routed
through this port.
5. In the 'Remove Prefix' box select how many digits to remove from the beginning of the
dialed number.
6. In the 'Add Prefix' box enter the digits to be added at the beginning of the number.
7. Press 'Save' to activate all changes.
Chapter 3.7: Dialing
Dialing from a mobile phone to a VoIP extension
To call a VoIP extension from a mobile phone through Port 1 with the default prefix settings:
Dialing from a VoIP extension to a mobile phone
To call from a VoIP extension to mobile phone with the default prefix settings:
Dialing through a specific port
To call a mobile phone through a pre‐defined specific port:
VoIP 2 All™ Series: 4 Channel Gateway User Manual
•
If two or more ports have the same prefix then the gateway will rotate calls
between the ports.
Dial the number of the SIM card in port 1.
•
Hear a dial tone.
•
Dial 9 plus the VoIP extension number (9 is the default prefix setting for VoIP)
•
i.e. 9100 (when 100 is the voip extension)
•
The call will route to the VoIP extension.
•
Pick up the VoIP extension and hear a dial tone.
•
Dial the GSM mobile number.
•
The call will route to Mobile phone through the first available cellular port.
•
If the mobile number start with 9, then you must setup the prefix of the VoIP to a
Note:
different number, otherwise the call will route to the VoIP
Set the 'Prefix' of this port to certain number (6).
•
Set the 'Remove Prefix' to the number of digits in that prefix (i.e. 1).
•
Save the prefixes settings.
•
Pick up the VoIP extension and hear a dial tone.
•
Dial the prefix (i.e. 6) and the mobile number. i.e. 605555555 (when 05555555 is the
•
mobile number)
.
13
