Viewing Port Logs
The port logs can be viewed from the web interface on the Port logging page or from the location where they have been saved.
The following table lists the file locations of the system logs.
System Logfile
Log Storage
Digi memory
Compact-flash card
Syslog server
NFS server
To view the port logs on the NFS server for port number 5, enter the following command:
more /mnt/nfs/port5data
Partial logfiles can also be viewed on the web interface by going to Serial port > Configuration > select a port you want to view >
Port logging.

Using the Configuration Menu

System Logging

System logging is a two part process.
First, the device being used to record the system logs must be configured.
Secondly, system logging must be configured for the system under System status and log.
System logs can be saved to the SERIMUX system memory (there is no need to configure the memory), a compact-flash card, an
NFS server, or a Syslog server.
Configure the System Log Device
To configure the compact-flash card for system logging, see Adding a Compact-flash Card on page 11. For an NFS or Syslog
server, do the following:
1. Access the configuration menu.
2. Choose Network configuration > NFS or SYSLOG server configuration.
3. Enter the desired parameters for the menu items.
4. Use the ESC key when all parameters are entered to return to the main menu.
5. Choose Save changes.

Figure 28- Port logging menu

File Location
/tmp/port#data
/mnt/flash/port#data
must be viewed from the syslog server
/mnt/nfs/port#data
24
