Hardware Specifications: SERIMUX 16 and SERIMUX 32 DC Powered

Attribute
Operating temperature
Storage temperature
Humidity
Power supply Internal
Power consumption
Fuse (internal)
Operating system
SDRAM
Flash memory
Size (In.) WxDxH: unpackaged
Size (In.) WxDxH: packaged
Weight: unpackaged
Weight: packaged

Hardware Specifications: SERIMUX 8 AC Powered

Attribute
Operating temperature
Storage temperature
Humidity
Power supply External
Power consumption
Operating system
SDRAM
Flash memory
Size (In.) WxDxH
Weight

LED Indicators

Use the LED indicators to confirm attachment to the network and that the SERIMUX is able to send and receive data.
LED
Power
Ready
System
PC
100Mbps
Ethernet
LINK
Act
Serial In Use
port Rx/Tx

About Serial Port Cabling

The SERIMUX simplifies cabling. The RJ45 8-pin configuration matches all SUN and Cisco RJ45 console port configurations,
enabling CAT 5 cabling without pinout concerns. Three DB-25 and one DB-9 adapters come in the package. A DB-25 male, a DB-
25 female, and a DB-9 adapter support console management applications. A DB-25 male adapter provides a modem
connection. See the cable adapter information that follows later in this chapter.
Note: The cable length restrictions common to RS-232 cables apply to the SERIMUX serial cable as well.
Function
On when power is supplied
On when system is ready to run
On when a PC device is running
On when 100Base-TX connection is detected
On when connected to an Ethernet network
Blinks when there is activity on the Ethernet port
On when the serial port is ready to run
Blinks when there is traffic on the serial port
57
40°F to 120°F (5°C to 50°C)
-20°F to 140°F (-29°C to 60°C)
10% to 90% non-condensing
36 - 72 Vdc, 1.2A (max)
0.25A /48Vdc, 12W (typical), 40W (max)
FUSE (Type L) AC250V, 2A
Linux Hard Hat embedded
64 megabytes
8 megabytes
17 x 8.5 x 1.75
20.375 x 15.25 x 4.75
5.8 lbs (2.63 kilograms)
8.6 lbs (3.9 kilograms)
40°F to 120°F (5°C to 50°C)
-20°F to 140°F (-29°C to 60°C)
10% to 90% non-condensing
100 - 240VAC, 50/60 Hz, 1.0A (max)
AC input: 0.05A /120VAC, 6W (typical), 12W (max)
DC input: 0.8A/5VAC, 4.5 W (typical), 8W (max)
Linux Hard Hat embedded
64 megabytes
8 megabytes
9.5 x 6.25 x 1.25
2.5 lbs (1.13 kilograms)
Value
Value
