- Page 1 ® VEEMUX Series SM-nXm-C5AV-LCD Audio/Video Matrix Switch via CAT5 Installation and Operation Manual Used with NTI ST-C5VA-600 (XTENDEX ) (NOT INCLUDED) MAN050 Rev 2/5/14...
- Page 2 TRADEMARK VEEMUX is a registered trademark of Network Technologies Inc in the U.S. and other countries COPYRIGHT Copyright © 2003, 2014 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION................................1 Materials ..................................1 Default User Name and Passwords ..........................2 FEATURES AND FUNCTIONS............................2 VEEMUX Features and Functions..........................2 XTENDEX Features and Functions..........................3 XTENDEX INSTALLATION............................. 4 Audio Compatibility ..............................4 The Local Unit................................4 The Remote Unit................................ - Page 4 DEVICE DISCOVERY TOOL ............................31 INTERCONNECTION CABLE WIRING METHOD ....................... 32 CAT5 Cable ................................32 Serial Cables ................................32 TROUBLESHOOTING ..............................33 APPENDIX ..................................34 INDEX.................................... 36 WARRANTY INFORMATION............................36 TABLE OF FIGURES Figure 1- Connect the Local Unit to the CPU............................. 4 Figure 2- Connect Local User Components to Local Unit ........................
-
Page 5: Introduction
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 INTRODUCTION The SM-nXm-C5AV-LCD (VEEMUX) is an Audio/Video Matrix switch via CAT5 designed to work in conjunction with the NTI ST-C5VA-600 or ST-C5SVA-600 CAT5 Audio/Video Extender (XTENDEX). Up to 32 audio/video sources can be connected to the VEEMUX via XTENDEX Local Units (n), each accessible by up to 16 audio/video displays connected via XTENDEX Remote Units (m). -
Page 6: Default User Name And Passwords
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Default User Name and Passwords admin The default Telnet password is (lower case letters only) . For instruction on using Telnet, see page Administrator The default Web Interface user name is (upper case letter for "A" only). -
Page 7: Xtendex Features And Functions
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Network Technologies Inc XTENDEX (Front View) (Rear View) ST-C5VA-600 Local Unit (VGA plus Audio) (not included) XTENDEX Features and Functions Green LED- power indicator- illuminates when power has been supplied to the unit... -
Page 8: Xtendex Installation
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 XTENDEX INSTALLATION (XTENDEX not included) Audio Compatibility • The audio input of the ST-C5VA-600 Audio/Video Extender is compatible with the following standard CPU audio outputs: • Line out - typically lime green in color •... -
Page 9: Figure 2- Connect Local User Components To Local Unit
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Make connections for a Local User (see Fig. 2) Connect the cable from the local user's VGA monitor to the female 15HD port on the Local Unit. Connect the cable from the local speakers into the 3.5mm jack on the local unit. -
Page 10: The Remote Unit
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 The Remote Unit Position the Remote Unit such that the CAT5 cable, the monitor cable, speaker cable, and the AC adapter power connector can each reach the Remote Unit comfortably. Connect the monitor cable to the female 15HD video connector on the Remote Unit. -
Page 11: Plug-In And Boot Up
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Plug-in and Boot Up Plug the power cord from the monitor into the power outlet. Connect each AC adapter power connector to the 9VDC ports on the Remote and Local Units. Make sure the power connectors go into each port all the way. -
Page 12: Veemux Installation
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 VEEMUX INSTALLATION Connect an ST-C5VA-600 Local Unit to an audio/video source as described on pages 4-5. Connect a CAT5 cable (wired as specified on page 27) between the ST-C5VA-600 Local Unit and VEEMUX connector "AV IN 1". -
Page 13: Figure 7- Maximum Total Cat5 Cable Length Cannot Exceed 600 Feet
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Note: This total length of CAT5 cable between the ST-C5VA-600 Remote and Local units cannot exceed 600 feet. (See Fig. 9) CAT5 CABLE CAT5 CABLE Local Remote VEEMUX Unit Unit Do Not Exceed 600 Feet Figure 7- Maximum total CAT5 cable length cannot exceed 600 feet 6. -
Page 14: Using The Veemux Switch
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 USING THE VEEMUX SWITCH The VEEMUX can be controlled by either of four methods: • Using the keypad of the front panel interface • Directly via an RS232 interface • Remotely via web interface •... -
Page 15: Keypad Control
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Keypad Control The front panel interface keypad and LCD enable the user to monitor switch status and route any user to any audio/video source (INPUT) on the switch. Along with the routing of the INPUTS to the user devices (OUTPUTS) the keypad and LCD allow the users to configure the RS-232 control interface and web server settings. -
Page 16: Set Serial Address
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Set Serial Address When selecting this menu item, the display shows the current serial address and the user is prompted to introduce a new serial address. One or two digits can be entered followed by <Enter>. The display will prompt if the address is successfully changed. -
Page 17: Set Wserver Timeout
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Set Wserver Timeout When selecting this menu item, the display shows the current webserver timeout period and offers optional values to change it to. Figure 17- Wserver Timeout Period The currently selected value is highlighted. -
Page 18: Rs232 Interface
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 This function is particularly useful to determine if a lack of sound from speakers is due to failed speakers, or lack of audio signal through the VEEMUX. If no signal is seen in this display, check all connections between the audio source, the XTENDEX, and the respective Input port on the VEEMUX. -
Page 19: Matrix Switcher's Control Program For Windows 9X, Nt, 2000 And Xp
The Matrix Switcher's Control Program performs best on monitors set to a screen resolution of at least 800 X 600. Instruction for using the Matrix Switcher’s Control Program is available by opening "MSCP Help" in the "NTI" program group once the program has been installed and is open on the screen. -
Page 20: Telnet Interface-Port 2000
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Telnet Interface-Port 2000 The Telnet Interface enables the user to control the switch using telnet client through an Ethernet connection. The telnet server listens on ports 2000 and 2005. Port 2000 is for an operator telnet session while port 2005 (must be enabled) is intended for a software control type session (see page 17). -
Page 21: Telnet Interface-Port 2005
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Telnet Interface-Port 2005 For a software control type of telnet interface session (versus operator telnet control through port 2000 as described on page 16), connect to the VEEMUX through the current IP address at port 2005. To do this, a connection to port 2005 must first be enabled (see Web Setup on page 23). -
Page 22: Cs- Connect Output Port To Input Port
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 CS- Connect Output Port to Input Port Command: Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8 Byte 9 ‘C’ ‘S’ Space Output – 1st digit Output –... -
Page 23: Ss_00- Disable Auto Status Mode
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 SS_00- Disable Auto Status Mode Command: Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 ‘S’ ‘S’ Space ‘0’ ‘0’ <CR> (0x53) (0x53) (0x20) (0x30) (0x30) (0x0D) Response: Byte 1 Byte 2 <CR>... -
Page 24: Web Interface
To open a SSL-encrypted connection, type: Address https://192.168.1.1 You will be prompted to accept a certificate. Accept the NTI certificate. A "Welcome Page" will appear. Figure 20- Web interface Welcome page Enter the Password Click on a link to the left to be prompted for a username and password. -
Page 25: Main Menu
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Main Menu The VEEMUX main menu provides control over all functions of the switch. The administrative menu includes options not available to other users with limited privileges. When logged in as a user other than the Administrator, only the VIDEO SWITCH, CHANGE PASSWORD, HELP, and LOGOUT options will be available. - Page 26 NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 To change a connection, click on the radio button (square image with circle in the center) that intersects the input and output columns. A black dot will be placed in the circle to indicate the selection. Then press the Submit button.
-
Page 27: Setup Pages
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Setup Pages These settings enable the user to configure the VEEMUX web interface connection. • This change will take a few seconds and automatically redirect the user to the IP address specified. Note: Since the webserver will be restarting all active connections will be logged out. -
Page 28: User Management
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 User Management The Administrator can assign usernames and passwords to up to 15 users. Once assigned, the Administrator can control which ports a user will have access to. Under the ADMINISTRATION menu, select “USER MANAGEMENT”. -
Page 29: Edit User
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Edit User To Edit a User, select “EDIT USER” from the USER MANAGEMENT section of the menu. Figure 28- Edit User settings From the Edit User page, the Administrator can change all user settings or delete the user altogether. -
Page 30: Video Input Names
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Video Input Names The Video Input Names page enables the Administrator to change the name of the input ports displayed on the Switch page. change a Video Input Name, enter the name of the input port for the desired port number, and press Save. -
Page 31: Outputs Scanning Sequences
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Outputs Scanning Sequences Figure 31- Outputs Scanning Sequences page The Outputs Scanning Sequences page displays the configuration of an automatic switching sequence from input (video source) to input for each output (monitor). The page displays:... -
Page 32: Update Firmware
2. Repeat the update process from the first step 2 above. 3. If you get another Fatal Error message, call NTI tech-support at 1-800-742-8324 or 330-562-7070. FYI: The VEEMUX should continue to run normally unless it is reset. However, damage may have occurred to... -
Page 33: Change Password Page
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Change Password Page Figure 33- Web interface Password page Use this page to change the password for accessing the web interface. (This password is also used for the telnet interface.) Be sure to make note of the new password exactly as it is case sensitive. The password must be between 5 and 16 characters in length and can be alphabetical or numeric. -
Page 34: Logout Page
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 Logout Page Figure 35- Web interface Logout page This page will enable the user to end the session and close the web interface connection. Click on the "Press Here to Continue Logout" button to exit the VEEMUX web interface. -
Page 35: Device Discovery Tool
DEVICE DISCOVERY TOOL In order to easily locate NTI Devices on a network, the NTI Device Discovery Tool may be used. A link to the Discovery Tool is provided on the web page that appears when you insert the instruction manual CD provided into your CD ROM drive. Either click on the link or browse the CD to locate the NTIDiscover.jar file. -
Page 36: Interconnection Cable Wiring Method
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 INTERCONNECTION CABLE WIRING METHOD CAT5 Cable The connection cable between the VEEMUX and XTENDEX remote and local units is terminated with RJ45 connectors and must be wired according to the EIA/TIA 568 B industry standard. Wiring is as per the table and Fig. 33 below. -
Page 37: Troubleshooting
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 14 15 16 17 18 19 20 21 22 23 24 25 Mating Face Mating Face of DB25 Male of a DB9 Male TROUBLESHOOTING PROBLEM: No audio Check all connections and power to all devices. Use the VU-Meter to determine if audio is passing through... -
Page 38: Appendix
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 APPENDIX Appendix A- Default Settings SETTING DEFAULT VALUE Login Username Administrator (case sensitive) Login Password admin (case sensitive) Serial Speed 9,600 bps Serial Address IP Address 192.168.1.1 Subnet Mask 255.255.255.0 Appendix B- General Information... -
Page 39: Figure 38- Mount Switch To A Rack
This NTI switch was designed to be directly mounted to a rack. It includes a mounting flange to make attachment easy. Install 4 cage nuts (supplied) to the rack in locations that line up with the holes (or slots) in the mounting flange on the NTI switch. -
Page 40: Index
NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5 INDEX 3.5mm jack, 6 Password-Telnet, 16 AC adapter, 7 powercord, 8 add user, 24 RS232 interface, 14 audio output, 13 Scanning Sequences, 27 CAT5 cable, 32 serial cables, 32 configuration menu, 11 Setup pages, 23...
