About the Display Events Section
This section of the user's guide shows the User's Guide Display
Events items for both 16-character (single line) and 32-character
keypad displays. While in the Display Events function, use the
COMMAND and ARROW keys to go forward or backward through
the list of events.

Arming and Disarming Event Displays

This displays any arming or disarming of system areas.
16-Character Display Description
ARM 3 12 1017 Area 3 was armed by user 12 on Oct. 17.
Press the SELECT key under 3 for the
area name, under 12 for the user name,
or under 1017 for the time the arming
occurred.
32-Character Display Description
A RM 5:10P 10 / 17 The Perimeter was armed at 5:10
PERIM ET ER Press any Select key to display the area
number and user number then any Select
key to display the user name.
Arming Event Types - There are 2 event type you may see here:
ARM - User armed the system
About the Display Events Section
This section of the user's guide shows the User's Guide Display
Events items for both 16-character (single line) and 32-character
keypad displays. While in the Display Events function, use the
COMMAND and ARROW keys to go forward or backward through
the list of events.
Arming and Disarming Event Displays
This displays any arming or disarming of system areas.
16-Character Display Description
ARM 3 12 1017 Area 3 was armed by user 12 on Oct. 17.
Press the Select key under 3 for the
area name, under 12 for the user name,
or under 1017 for the time the arming
occurred.
32-Character Display Description
A RM 5:10P 10/ 17 The Perimeter was armed at 5:10
PERIM ET ER Press any Select key to display the area
number and user number then any
Select key to display the user name.
Arming Event Types - There are 2 event type you may see here:
ARM - User armed the system
.
PM
DIS - User disarmed the system
.
PM
DIS - User disarmed the system

Zone Event Displays

This section displays alarms, troubles, and other events that could
occur on your protection zones.
16-Character Display Description
2 BURG ALR 1017 A burglary alarm occurred on zone 2.
Press the right SELECT key for the time
the alarm occurred.
32-Character Display Description
A LR 10: 23P 10/17 An alarm occurred at 10:23
BASEM ENT DOOR Press any SELECT key to see the zone
number and zone type.
Zone Type - There are 7 possible zone types you may see here.
FIRE - Fire PANC - Panic
EMRG - Emergency SUPV - Supervisory
AUX1 - Auxiliary 1 AUX2 - Auxiliary 2
Event Types - There are 6 event types you may see here:
ALR - Alarm TBL - Trouble
LOW - Low battery MIS - Missing wireless transmitter
Note: LOW and MIS are for wireless systems only.
Zone Event Displays
This section displays alarms, troubles, and other events that could
occur on your protection zones.
16-Character Display Description
2 BURG ALR 1017 A burglary alarm occurred on zone 2.
Press the right Select key for the time the
alarm occurred.
32-Character Display Description
A LR 10: 23P 10/17 An alarm occurred at 10:23
BAS EM ENT DOOR Press any Select key to see the zone
number and zone type.
Zone Type - There are 7 possible zone types you may see here.
FIRE - Fire PANC - Panic
EMRG - Emergency SUPV - Supervisory
AUX1 - Auxiliary 1 AUX2 - Auxiliary 2
Event Types - There are 6 event type you may see here:
ALR - Alarm TBL - Trouble
LOW - Low battery MIS - Missing wireless transmitter
Note: LOW and MIS are for wireless systems only.
on Oct. 17.
PM
BURG - Burglary
RST - Restore
User Menu
29
on Oct. 17.
PM
BURG - Burglary
RST - Restore
