Zone Monitor Browser - Security Command Executive XR200 User Manual

Zone Monitor Browser

Appendix
40
Zone Monitor Browser
Appendix
40
Start Here
Access the User Menu. Press
ZONE MONITOR?
COMMAND until ZONE MONITOR?
displays. Press any SELECT key.
ALL NBR Press the SELECT key under NBR.
ZONE: – ADD RMV Press either of the two left SELECT keys.
This prompt allows you to search for a
SELECT AREA . . .
zone by area. Press the COMMAND key
to scroll through the list of areas.
COMMAND
When the area where the zone is
FRONT OFFICE
located is displayed, press any SELECT
key.
Press the COMMAND key to scroll
SELECT ZONE . . .
through the list of all zone names.
COMMAND
The display shows the zone number.
Start Here
Access the User Menu. Press
ZONE MONITOR?
COMMAND until ZONE MONITOR?
displays. Press any SELECT key.
ALL NBR
Press the SELECT key under NBR.
ZONE: – ADD RMV
Press either of the two left SELECT keys.
This prompt allows you to search for a
SELECT AREA . . .
zone by area. Press the COMMAND key
to scroll through the list of areas.
COMMAND
When the area where the zone is
FRONT OFFICE
located is displayed, press any SELECT
key.
Press the COMMAND key to scroll
SELECT ZONE . . .
through the list of all zone names.
COMMAND
The display shows the zone number.
When the correct zone name is
EAST DOOR
displayed, press any SELECT key.
ZONE:012 ADD RMV
Selecting ADD
puts the zone in
the monitor mode.
When the correct zone name is
EAST DOOR
displayed, press any SELECT key.
ZONE:012 ADD RMV
Selecting ADD
puts the zone in
the monitor mode.
Selecting RMV removes
the zone from the monitor
mode.
Selecting RMV removes
the zone from the monitor
mode.
