Zone Event Displays

This section displays alarms, troubles, and other events that could
occur on your system's protection zones.
Display Description
JONES RESIDENCE A burglary alarm occurred on zone 2.
2 BURG ALR Press the SELECT key under the zone
number to display the custom zone name
programmed into the system.
Zone Type - There are 7 possible zone types you may see here.
F I RE - Fire PANC - Panic
E MRG - Emergency SUPV - Supervisory
AUX 1 - Auxiliary 1 AUX 2 - Auxiliary 2
Event Types - There are 3 event type you may see here:
ALR - Alarm T B L - Trouble
18

Arming and Disarming Event Displays

This displays any arming or disarming of system areas.
Display
JONES RESIDENCE
ARM ALL
Arming Event Types - There are 2 event type you may see here:
ARM - An authorized user armed the system
DIS - An authorized user disarmed the system
BURG - Burglary
Area Descriptions - There are 3 area names you may see here:
ALL - All areas in the system were armed or disarmed.
PERIM - The Perimeter only was armed or disarmed.
SLEEP - The Perimeter and Interior areas in a Home/Away system
were armed or disarmed.
RST - Restore
User Numbers - There are 12 user numbers available in your
system. Each code has a user number (1 to 12) that is used by the
system to identify the person using it. A user number of 0 (zero) is an
arming or disarming that did not require a user code; for example:
arming with a mechanical keyswitch.
Description
All areas of the system were armed by
6 user number 6.
User Menu
