Door Access Event Displays

This displays the keypad address where a *Door Access occurred
and the user number of the person granted access.
16-Character Display
Description
DOOR 3 024 1017
Door (keypad) #3 was accessed by
user 24 on Oct. 17. Press the SELECT
key under 1017 for the time of occurrence
or under 024 for the user name.
32-Character Display
Description
ACC
5:18P
10/17
Door (keypad) #3 was accessed by
DOOR 3 USER:024
user 24 on Oct. 17. Press the SELECT
key under 1017 for the time of occurrence
or under 024 for the user name.
About Door Access
Door Access is a feature available only on certain Security Command
keypads that contain a built-in door releasing relay. When low
voltage power for an electric door strike or magnetic lock is connected
to the relay's contacts, users entering a valid user code can release
the lock and gain access to the protected area.
The Display Events feature logs the user number and name of the
person granted access, the date and time, and from which keypad
they entered their code.
Door Access Event Displays
This displays the keypad address where a *Door Access occurred
and the user number of the person granted access.
16-Character Display
Description
DOOR 3 024 1017
Door (keypad) #3 was accessed by
user 24 on Oct. 17. Press the Select key
under 1017 for the time of occurrence or
under 024 for the user name.
32-Character Display
Description
ACC
5:18P
10/17
Door (keypad) #3 was accessed by
DOOR 3 USER:024
user 24 on Oct. 17. Press the Select key
under 1017 for the time of occurrence or
under 024 for the user name.
About Door Access
Door Access is a feature available only on certain Security Command
keypads that contain a built-in door releasing relay. When low
voltage power for an electric door strike or magnetic lock is connected
to the relay's contacts, only users entering a valid user code can
release the lock and gain access to the protected area.
The Display Events feature logs the user number and name of the
person granted access, the date and time, and from which keypad
they entered their code.

Schedule Change Event Displays

This displays Changes made to the system's schedules.
16-Character Display
Description
PRM MON 024 1017
A Permanent schedule for Monday was
changed by user 24 on Oct. 17. Press
the SELECT key under 1017 for the
time of occurrence or under 024 for the
user name.
32-Character Display
Description
PRM
9:41A 10/17
A Permanent schedule for Monday was
SCH MON USER:024
changed by user 24 on Oct. 17.
Schedule Types - There are 4 possible schedule types:
PRM - Permanent
TMP - Temporary
SEC - Secondary
MON - This is the day of the week in which the schedule change
occurred. The days are displayed using three letters. Press the
SELECT key under the day of the week to display the scheduled
Opening time and once again for the scheduled Closing time.
024 - User number of the person who made the change. Press the
SELECT key under this number to display the user's name.
Schedule Change Event Displays
This displays Changes made to the system's schedules.
16-Character Display
Description
PRM MON 024 1017
A Permanent schedule for Monday was
changed by user 24 on Oct. 17. Press
the Select key under 1017 for the time of
occurrence or under 024 for the user
name.
32-Character Display
Description
PRM
9:41A 10/17
A Permanent schedule for Monday was
SCH MON USER:024
changed by user 24 on Oct. 17.
Schedule Types - There are 4 possible schedule types:
PRM - Permanent
TMP - Temporary
SEC - Secondary
MON - This is the day of the week in which the schedule change
occurred. The days are displayed using three letters. Press the
SELECT key under the day of the week to display the scheduled
Opening time and once again for the scheduled Closing time.
024 - User number of the person who made the change. Press the
SELECT key under this number to display the user's name.
PRI - Primary
User Menu
31
PRI - Primary
User Menu
31
