User Code Change Event Displays

This displays any addition, deletion, or change to a user code.
16-Character Display
12 ADD 19 1017
32-Character Display
A DD 11: 41A 10 / 17
US:19 BY US:1 2
User Code Event Types - There are 3 event types you may see here:
ADD - User added DEL - User deleted
CHG - User code or authority level has been changed.
Supervisory Event Displays
This displays the date and time of an automatic test report.
16-Character Display
AUTO RECALL 1017
32-Character Display
MSG 11: 58P 10 / 17
AUTO R ECALL
30
User Menu
User Code Change Event Displays
This displays any addition, deletion, or change to a user code.
16-Character Display
12 ADD 19 1017
32-Character Display
A DD 11: 41A 10 / 17
US:19 BY US:1 2
User Code Event Types - There are 3 event type you may see here:
ADD - User added DEL - User deleted
CHG - User code or authority level has been changed.
Supervisory Event Displays
This displays the date and time of an automatic test report.
16-Character Display
AUTO RECALL 1017
32-Character Display
MSG 11: 58P 10 / 17
AUTO R ECALL
30 User Menu
Description
User 12 added user 19 on Oct. 17. Press
the right SELECT key for the time this
occurred.
Description
User 19 added by user 12 at 11:41
Press the Select key under either user
(US:) number for the user name.
Description
The test report was sent on Oct. 17.
Description
The test report was sent to the central
station at the date and time shown.
Description
User 12 added user 19 on Oct. 17.
Press the right Select key for the time
this occurred.
Description
User 19 added by user 12 at 11:41
Press the Select key under either user
(US:) number for the user name.
Description
The test report was sent on Oct. 17.
Description
The test report was sent to the central
station at the date and time shown.

System Monitor Event Displays

This displays any problems with the system's AC power, battery, or
phone line(s) or any opening of a tampered panel box.
16-Character Display
POWER TBL 1017
32-Character Display
.
TBL 11:41A 10/17
AM
POW ER
System Monitor Event Types - There are 2 event types:
TBL - Trouble
System Monitor Event Names - There are 5 system monitors:
POWER - AC power to panel
LINE 1 - Phone line number 1
LINE 2 - Phone line number 2
System Monitor Event Displays
This displays any problems with the system's AC power, battery, or
phone line(s) or any opening of a tampered panel box.
16-Character Display
POWER TBL 1017
32-Character Display
. TBL 11:41A 10/17
AM
POW ER
System Monitor Event Types - There are 2 event types:
TBL - Trouble
System Monitor Event Names - There are 5 system monitors:
POWER - AC power to panel
LINE 1 - Phone line number 1
LINE 2 - Phone line number 2
Description
An AC failure occurred on Oct. 17. Press
the SELECT key under 1017 for the time.
Description
An AC failure occurred on Oct. 17. Press
the SELECT key under 1017 for the time
the failure occurred.
RST - Restore
BATTERY - On panel
TAMPER - On panel box
Description
An AC failure occurred on Oct. 17. Press
the Select key under 1017 for the time.
Description
An AC failure occurred on Oct. 17. Press
the Select key under 1017 for the time
the failure occurred.
RST - Restore
BATTERY - On panel
TAMPER - On panel box
