User Codes
continued
Programming Custom User Codes
In addition to the preset authority levels, you can also create custom
authority levels by selecting the CUSTOM option at the time the user
is being added to the system. This option allows you to assign
specific User Menu access to individual users.
Adding User Codes:
1. Access the User Menu.
2. Press COMMAND until USER CODES? displays. (NOTE: You
must have a level 9 authority. If you enter the User Menu with
a lower authority, the keypad will not display USER CODES?.)
3. Press any SELECT key. The keypad displays ADD DEL CHG.
4. Press the SELECT key under ADD to add a new user code.
5. At the USER NUMBER:- prompt, enter a user number and
press COMMAND. The display changes to CODE NO:- .
6. Enter a user code of 3 to 5 digits (4 digits on the Home/Away
system) and press COMMAND. The user enters this number
each time they arm, disarm, or make changes. If using access
cards, present the card instead of entering a code. After the
code is entered, the display changes to USER NUMBER ###.
7. A 16 character name may be entered to identify the user. Press
any top row key to clear the current name. You may then enter
the new name. After the name is entered, press COMMAND.
See Entering Custom Names in the Appendix of this User's
Guide.
8. Areas systems only - The display changes to AREAS: # # # #
(# = area number). Add or remove access to one or more areas
by pressing the corresponding number keys. Press COMMAND.
Note: You may only add areas that are assigned to your code.
User Codes
continued
Programming Custom User Codes
In addition to the preset authority levels, you can also create custom
authority levels by selecting the CUSTOM option at the time the user
is being added to the system. This option allows you to assign
specific User Menu access to individual users.
Adding User Codes:
1. Access the User Menu.
2. Press COMMAND until USER CODES? displays. (NOTE: You
must have a level 9 authority. If you enter the User Menu with
a lower authority, the keypad will not display USER CODES?.)
3. Press any SELECT key. The keypad displays ADD DEL CHG.
4. Press the SELECT key under ADD to add a new user code.
5. At the USER NUMBER:- prompt, enter a user number and
press COMMAND. The display changes to CODE NO:- .
6. Enter a user code of 3 to 5 digits (4 digits on the Home/Away
system) and press COMMAND. The user enters this number
each time they arm, disarm, or make changes. If using access
cards, present the card instead of entering a code. After the
code is entered, the display changes to USER NUMBER ###.
7. A 16 character name may be entered to identify the user. Press
any top row key to clear the current name. You may then enter
the new name. After the name is entered, press COMMAND.
See Entering Custom Names in the appendix of this User's
Guide.
8. Areas systems only - The display changes to AREAS: # # # #
(# = area number). Add or remove access to one or more areas
by pressing the corresponding number keys. Press COMMAND.
Note: You may only add areas that are assigned to your code.
9. The display changes to LEVEL
assign a standard set of authorized functions as outlined in the
User Code Authority Levels table on the previous page.
10. At the LEVEL: - display, enter an authority level from 1 to 9.
Press COMMAND. The displays shows USER # ADDED.
11. Select CUSTOM to customize the functions you want the user
to access. This allows users to have certain capabilities outside
of a standard authority level. The following chart shows the
custom menu with default selections.
ARM/DIS (arm & disarm)
NO
ALM SLNC (alarm silence) NO
SNSR RST (sensor reset)
NO
DOOR ACS (door access)
NO
ARM AREA (armed areas) NO
OUTPUTS (outputs on off)
NO
ZN STATS (zone status)
NO
BYPAS ZN (bypass zones) NO
ZONE MON (zone monitor) NO
*
• NO makes this a permanent user code.
• YES makes this a temporary code that expires in 7 days.
12. Press the ARROW key to exit the User Menu.
Note: Customized codes are not restricted to the schedules.
Browser Feature
Refer to the Appendix at the back of this guide for a diagram showing
you how to use the buitl-in Add User Codes browser.
9. The display changes to LEVEL
assign a standard set of authorized functions as outlined in the
User Code Authority Levels table on the previous page.
10. At the LEVEL: - display, enter an authority level from 1 to 9.
Press COMMAND. The displays shows USER # ADDED.
11. Select CUSTOM to customize the functions you want the user
to access. This allows users to have certain capabilities outside
of a standard authority level. The following chart shows the
custom menu with default selections.
ARM/DIS (arm & disarm)
NO
ALM SLNC (alarm silence) NO
SNSR RST (sensor reset)
NO
DOOR ACS (door access)
NO
ARM AREA (armed areas) NO
OUTPUTS (outputs on off)
NO
ZN STATS (zone status)
NO
BYPAS ZN (bypass zones) NO
ZONE MON (zone monitor) NO
*
• NO makes this a permanent user code.
• YES makes this a temporary code that expires in 7 days.
12. Press the ARROW key to exit the User Menu.
Note: Customized codes are not restricted to the schedules.
Browser Feature
Refer to the Appendix at the back of this guide for a diagram showing
you how to use the buitl-in Add User Codes browser.
CUSTOM. Select LEVEL to
SYS STAT (system status)
SYS TEST (system test)
USR CODE (user codes)
SCHEDULS (schedules)
TIME (day, date, and time)
DIS EVNT (display events)
EXTEND (extend closing)
*
TEMP CODE (temporary code) NO
User Menu
CUSTOM. Select LEVEL to
SYS STAT (system status)
SYS TEST (system test)
USR CODE (user codes)
SCHEDULS (schedules)
TIME (day, date, and time)
DIS EVNT (display events)
EXTEND (extend closing)
*
TEMP CODE (temporary code) NO
User Menu
NO
NO
NO
NO
NO
NO
NO
21
NO
NO
NO
NO
NO
NO
NO
21
