Zone Bypass Event Displays

This displays the bypassing of system zones.
16-Character Display
26 BYPS 1 2 1017
32-Character Display
BYP 5:18P 10 / 17
EAST W I NDOW
Bypass Event Types - There are 4 event types:
BYP - Bypass RST - Restore
FLT - Zone Fault
Note: You may sometimes see the user as SWG. This is short for
Swinger Bypass, which is an automatic function that allows the
system to bypass a zone.
32
User Menu
Zone Bypass Event Displays
This displays the bypassing of system zones.
16-Character Display
26 BYPS 1 2 1017
32-Character Display
BYP 5:18P 10 / 17
EAST W I NDOW
Bypass Event Types - There are 4 event types:
BYP - Bypass RST - Restore
FLT - Zone Fault
Note: You may sometimes see the user as SWG. This is short for
Swinger Bypass which is an automatic function that allows the
system to bypass a zone.
32 User Menu
Description
Zone 26 bypassed by user 12. Press the
left SELECT key for the zone name and
the right SELECT key for the time.
Description
The east window zone was bypassed.
Press a SELECT key for the zone
number and user number. Press again
for the user name.
FRC - Force Arm
Description
Zone 26 bypassed by user 12. Press the
left Select key for the zone name and
the right Select key for the time.
Description
The east window zone was bypassed.
Press a Select key for the zone number
and user number. Press again for the
user name.
FRC - Force Arm
SERVICE REQUEST?
This feature of the User Menu allows you to just press any top row
SELECT key while SERVICE REQUEST? is displayed and have the
system automatically send a "Request for Service" message to the
central station. The display changes to REQUEST MADE
momentarily to confirm your request was sent.
Our service department will then contact you to arrange a service
appointment.
SERVICE REQUEST?
This feature of the User Menu allows you to just press any top row
SELECT key while SERVICE REQUEST? is displayed and have the
system automatically send a "Request for Service" message to the
central station. The display changes to REQUEST MADE
momentarily to confirm your request was sent.
Our service department will then contact you to arrange a service
appointment.
