During A Call - ASCOM d62 Talker User Manual

User Manual
Ascom d62 DECT Handset
4 Select "Search by name".
5 Enter the first name and/or last name, the whole name does not have to be entered.
6 Press "Search".
7 Press the soft key "Call" or Off-hook key to make the call.
6.3.9 Dial a Number from the Company Phonebook
1 Open the menu by pressing the confirmation button, or the soft key "Menu".
2 Select "Contacts".
3 Select "Call contact".
4 The local and company phonebook appears in the same list but the company names
are indicated by a "Locked entry" icon
list, or search name/number by entering characters in the "Search" field.
5 Press the soft key "Call" or the Off-hook key to make the call.
6.4

During a Call

Note: Some of these functions are system dependent. The parameters are set up in the
Portable Device Manager (PDM), see Configuration Manual, Ascom d62 DECT Handset,
TD 92639GB, and Installation and Operational Manual, Portable Device Manager (PDM),
Windows version, TD 92325GB.
If the handset is configured via PDM, it is possible to call a predefined emergency number
while the handset/keypad is locked. When calling from a locked handset, it is only possible
to access the Microphone on/off function by pressing the soft key "More". However, the
entire In Call menu is accessible when calling from a handset with locked keypad.
6.4.1 Adjust the Volume during a Call
Press the "Volume up" button to increase the volume, and the "Volume down" button to
decrease the volume. The handset will now store and keep the new volume level. It is also
possible to use the navigation key,
6.4.2 Open Contacts during the Call
1 Press the soft key "More" during the call.
2 Select "Contacts".
3 Press "Select".
4 Select "Call contact" for searching a local or company phonebook contact, or select
"Central phonebook" for searching a central phonebook contact.
5 Press "Select".
6 Select or search contact.
NOTE: It is possible to call the selected contact by pressing "Call". When calling the contact,
the first call will be put on hold. See also
30.
6.4.3 Turn the Microphone on/off during a Call
1 Press the soft key "More" during the call.
2 Select "Microphone off".
15 June 2012 / Ver. G
in front of the name. Select contact from
and to adjust the volume.
6.4.6 Start a New Call during Conversation
TD 92477EN
on page
29
