ASCOM d62 Talker User Manual page 79

User Manual
Ascom d62 DECT Handset
Error or Warning Messages
Display shows
No access
No System. The handset
beeps once a minute
(during max 30
minutes) with a low
tone followed by a high
tone (if enabled, the
vibrator also follows the
beeps).
The message Failed is
displayed when the
handset tries to
download an ECG
waveform image.
SERVICE NEEDED
Parameters corrupt
Note: This display
message is only shown
in English.
SERVICE NEEDED
Invalid IPDI
Note: This display
message is only shown
in English.
Enter PIN code
Battery low, charge now The battery level is low.
Phonebook is not
available at the
moment.
Voice mail number not
defined
15 June 2012 / Ver. G
Probable cause
The network is in range, but no
access rights.
The handset is out of coverage or
handset is defective.
The IP-DECT wireless connection
point is overloaded with too many
calls.
The handset is defective.
Easy replacement procedure not
followed correctly or failure during
easy replacement procedure.
The handset's lock is activated.
The phonebook does not respond,
not available at the moment.
There is no Voice mail number
defined in the handset.
TD 92477EN
Action or comment
Switch handset off and then
switch it on again or contact
system administrator.
Stop the beep with the Sound
off key and go into range.
Note: When re-entering the
coverage area it can take a
couple of minutes before the
handset automatically has
registered into the system.
or
contact system administrator.
Go see the patient. The ECG
Monitoring functionality will
start working when the IP-DECT
connection point is no longer
overloaded.
Select the reset option on the
middle soft key and upgrade
the handset's software to
version 3.0.0 or greater. If this
is not available or the problem
persists send the handset for
service.
Send the handset for service.
Enter the required PIN code. If
PIN code lost enter new via PDM
or do a factory reset via PDM.
Charge or replace the battery.
Try again later or if fault
persists do a factory reset via
admin menu or PDM.
Define a Voice mail number via
PDM.
75
