User Manual
Ascom d62 DECT Handset
12 Space
To add space between text
13 Sound off key
To turn on/off audible signals in idle mode, silencing the ring signal at incoming
call, and to turn on/off the microphone during a call.
14 Tactile indicators
There are two tactile indicators to indicate the centre of the key pad
15 End and On/Off key
Combined button; to end a call, to return to standby mode, and to switch the
handset on/off by long press.
16 Color display
The full graphic type display is 128 pixels wide and 160 pixels high. The display
has multiple colors and backlighting.
17 Headset connector
The headset connector is for connecting a headset. The connector is protected
against dust by using the headset connector cover.
18 LED
Indicates incoming call, messaging, low battery, and charging.
3.1

The Ascom d62 DECT Handset

IMPORTANT: The handset may retain small metal objects around the mouthcap or earcap
region.
Case
The plastic cover parts are made of durable PC/ABS material.
Antenna
The antenna is integrated inside the handset.
Loudspeaker
The handset has a separate loudspeaker for the loudspeaking function. It is placed on the
back side of the handset.
Microphone
The microphone is placed on the front bottom side of the handset.
Clip
There are two different belt clip options to the handset; a hinge-type clip (standard), and a
swivel-type clip. See
type Clip on page 82. Use the clip to attach the handset to a pocket, belt, or similar. It is also
possible to use the handset without any clip on, see
83.
Battery
The battery is a rechargeable Li-pol battery, placed under a battery cover. See
Replace the Battery
15 June 2012 / Ver. G
16.3 Attach the Hinge-type Clip
on page 78.
on page 82, or 16.4 Attach the Swivel-
16.5 Attach Cover for No Clip
TD 92477EN
on page
16.1.4
9
