User Manual
Ascom d62 DECT Handset
3

Descriptions

2
3
4
5
6
7
8
9
10
Figure 1. Description of the Handset d62.
1 Multifunction/Alarm button
This button can be used as a short cut to functions; long or double press modes. In
the d62 Protector, the button is used as a push button alarm only.
2 Earpiece speaker
3 Volume button (up)
To increase the speaker volume
4 Volume button (down)
To decrease the speaker volume
5 Mute and PTT button
To turn on/off audible signals in idle mode, silencing the ring signal at incoming
call, and to turn on/off the microphone during a call.
6 Soft keys
The 3 Soft keys can be pre-programmed or used with GUI
7 Off-hook key
To answer a call, to pre-dial a number, and as a short cut to the Call list.
8 Five-way navigation key
Navigation key with Left, Right, Up, Down, and Confirmation (in the middle). It is
also possible to program these keys for short cuts, except the middle key.
9 Voice mail access
A quick access to the handset's Voice mail. This is a system dependent feature.
10 Key lock and Upper/Lower case
Combined key lock and Upper/Lower Case
11 Microphone
15 June 2012 / Ver. G
