EP850 All-In-One EPIC Board User's Manual
1.1

Specifications

CPU
® TM
Intel Core
Chipset
Cantiga GM/GL45 and ICH9M
Bus Clock
677/800/1066 MHz FSB
BIOS
American Megatrends Inc. BIOS.
8Mbit SPI Flash, DMI, Plug and Play
SmartView for multiple LCD type selection, display
mode option and application extension features
"Load Optimized Default" to backup customized Setting in
the BIOS flash chip to prevent from CMOS battery fail
System Memory
One 204-pin DDR3 SO-DIMM socket
Maximum to 4GB DDR3 memory
L2 Cache
Integrated in CPU
TM
CompactFlash
One CompactFlash
Onboard Multi I/O
Two RS-232
Two SATA-II connectors
USB Interface
Six USB ports with fuse protection and complies with USB
Spec. Rev. 2.0
Real Time Clock
Integrated Intel
Watchdog Timer
1~255 seconds; up to 255 levels
2
2 Duo and C-M Penryn processors
Socket
TM
Type II Socket
®
ICH9M
Introduction
