2.4

Connectors

Connectors connect the CPU card with other parts of the system.
Loose or improper connection might cause problems. Make sure all
connectors are properly and firmly connected. Here is a summary table
shows you all connectors on the EP850 Series.
Connectors
Power Connector
PCI 104 Connector
Audio Connector
Front Panel Connector
Output Power Connector
SMBus Connector
LVDS Backlight Connector
LVDS Connector
Serial Port2 Connector
Digital I/O Connector
Serial Port1 Connector
Mini Dim Keyboard/Mouse Connector
VGA Connector
LAN1 Connector
LAN2 Connector
CPU FAN Connector
System FAN Connector
SATA1 Connector
SATA2 Connector
USB Connector
USB Connector
USB Connector
CF Connector
DDRIII RAM Connector
Jumpers and Connectors
EP850 All-In-One EPIC Board User's Manual
Label
ATX2
CN1
CN2
CN3
CN4
CN5
CN6
CN9
CN10
CN11
CN12
CN13
CN14
LAN1
LAN2
FAN1
FAN2
SATA1
SATA2
USB1
USB2
USB3
SCF1
SDIMM1
15
