2.3.5

COM1~COM2 Mode Selection Jumpers (JP11,

JP13)

These jumpers select the COM1, COM2 ports' DCD and RI mode.

Description

COM1 (JP13)

Pin 1=12V

Pin 1=5V

*Pin 1=DCD

(Default)

Pin 9=12V

Pin 9=5V

*Pin 9=RI

(Default)

Function

Jumper Setting
