EP850 All-In-One EPIC Board User's Manual
2.4.14 CPU & System Fan Connectors (FAN1, FAN2)
Fan1 is a fan connector for CPU, and FAN2 for system. Pentium
microprocessors require a fan for heat dispensing. The CPU/System
fan connectors respectively provide power to the CPU/System fans.
FAN1
Pin
1
2
3
FAN2
Pin
1
2
3

2.4.15 SATA Connectors (SATA1, SATA2)

The SATA connectors SATA1 and SATA2 are for high-speed SATA
interface port and it can be connected to serial ATA hard disk devices.
Pin
1 GND
3 SATA_TX-
5 SATA_RX-
7 GND
24
Siganl
Ground
+12V
Sensor
Siganl
Ground
+12V
Sensor
Signal Pin
2 SATA_TX+
4 GND
6 SATA_RX+
Signal
Jumpers and Connectors
