Graphics
Integrated in the Cantiga GM/GL45 for LVDS, CRT,
DisplayPort
LVDS port from LFP support 24/48-bit as 1*40-pin
connector
VGA from DAC port as D-sub 15-pin connector
External DisplayPort via JST 20-pin connector for cabling
configuration
Expansion Interface
One PCI-104 for 32-bit/33 MHz PCI expansion with PCI v1.1
compliant
Ethernet
Dual Giga-bit Ethernet
Two RTL8111B Giga-bit Ethernet controllers via PCIe x1
with integrated Boot ROM with RPL and PXE
Audio
Realtek High Definition codec audio
MIC-in, Line-out
Power Management
ACPI (Advanced Configuration and Power Interface)
Form Factor
EPIC form factor
NOTE All specifications and images are subject to change
without notice.
