EP850 All-In-One EPIC Board User's Manual

2.3.6

USB Voltage Selection Jumpers (JP9, JP10,

JP12)

This jumper is to select the voltage for USB interface.

Description

USB Voltage

Selection

2.3.7

This jumper is to select the voltage for LVDS interface.

Description

LVDS Voltage

Selection

Function

5V (Default)

5V_SBY

Function

3.3V (Default)

Jumper Setting

Jumpers and Connectors
