Watchdog Timer Setting

After the system stops working for a while, it can be auto-reset by the

Watchdog Timer. The integrated Watchdog Timer can be set up in the

system reset mode by program.

Timeout Value Range

1 to 255

Minute / Second

Program Sample

Watchdog Timer can be set to system reset after 5-second timeout.

2E, 87

2E, 07

2F, 00

2E, 2B

2F, 00

2E, 07

2F, 08

2E, 30

2F, 01

2E, F3

2F, N

2E, F4

2F, M

EP850 All-In-One EPIC Board User's Manual

WATCHDOG TIMER

Logical Device 0

Set WDT Funtion Enable

Logical Device 8

Activate

Set Second

N = 0 or 4

Set Value

M = 00 ~ FF

APPENDIX A
