Tunnel – Connect
Mode Page
Settings
Mode
Remote Address
Remote Port
Local Port
Protocol
TCP Keep Alive
AES Encrypt Key
AES Decrypt Key
IntelliBox-I/O 2100 User Guide
7: Network, Serial Line, Tunnel, and Modbus Settings

Table 7-7 Tunnel -- Connect Mode Settings

Description
Select the method used to start a tunnel in Accept Mode. Choices
are:
Disable = do not accept an incoming connection.
Always = accept an incoming connection. (default)
Any Character = start waiting for an incoming connection when any
character is read on the serial line.
Start Character = start waiting for an incoming connection when the
start character for the selected tunnel is read on the serial line.
Modem Control Asserted = start waiting for an incoming connection
as long as the Modem Control pin (DSR) is asserted on the serial line
until a connection is made.
Modem Emulation = start waiting for an incoming connection when
triggered by modem emulation AT commands. Connect Mode must
also be set to Modem Emulation.
Enter the address of the remote host to which the selected tunnel will
connect. Default is <none>.
Enter the number of the remote port to which the selected tunnel will
connect. Default is <none>.
Enter the number of the local port used to receive (or listen for)
packets. Random by default, but can be overridden.
Select the protocol to be used on the connection. Choices are:
TCP (default)
SSH SSL
TCP
TCP/AES
Telnet
UDP
UDP/AES
Specifies the number of milliseconds the IntelliBox waits during an
inactive connection before checking the status of the connection. If
the IntelliBox does not receive a response from the remote host, it
drops that connection.
Specify the Advanced Encryption Standard (AES) key string to be used
for encrypting outgoing data in Connect Mode tunneling. Then, select the
key form:
Text
Hexadecimal
Specify the Advanced Encryption Standard (AES) key string to be used
for decrypting incoming data in Connect Mode tunneling. Then, select the
key form:
Text
Hexadecimal
